Selection Guide
Iv (mcd) [2]
Viewing
Part No.
Dice
Lens Type
@ 10mA
Min.
Typ.
Angle [1]
2 θ 1/2
WP914PGT
Pure Green (GaP)
Green Transparent
0.8
2
90 °
Notes:
1. θ 1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value.
2. Luminous intensity/ luminous Flux: +/-15%.
3.Luminous intensity value is traceable to the CIE127-2007 compliant national standards.
Electrical / Optical Characteristics at TA=25°C
Symbol
λ peak
λ D [1]
Δλ 1/2
C
V F [2]
I R
Parameter
Peak Wavelength
Dominant Wavelength
Spectral Line Half-width
Capacitance
Forward Voltage
Reverse Current
Device
Pure Green
Pure Green
Pure Green
Pure Green
Pure Green
Pure Green
Typ.
557
557
30
45
2.25
Max.
2.5
10
Units
nm
nm
nm
pF
V
uA
Test Conditions
I F =20mA
I F =20mA
I F =20mA
V F =0V;f=1MHz
I F =20mA
V R = 5V
Notes:
1.Wavelength: +/-1nm.
2. Forward Voltage: +/-0.1V.
3. Wavelength value is traceable to the CIE127-2007 compliant national standards.
Absolute Maximum Ratings at TA=25°C
Parameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Lead Solder Temperature [3]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
3. 5mm below package base.
Pure Green
62.5
25
135
5
-40°C To +85°C
260°C For 3 Seconds
260°C For 5 Seconds
Units
mW
mA
mA
V
SPEC NO: DSAE9441
APPROVED: WYNEC
REV NO: V.6B
CHECKED: Allen Liu
DATE: MAY/06/2013
DRAWN: Y.Liu
PAGE: 2 OF 6
ERP: 1101010173
